Pressure and Density
Pascal's Principle
Pressure with depth
Buoyancy
Flow Rate and Bernoulli's Principle
Classic Movie Cars
100
What is the difference between gauge pressure and absolute pressure?
Absolute pressure is gauge pressure plus atmospheric pressure
100
What is the formula for pascal's principle?
F1/A1=F2/A2
100
When determining the pressure at any depth of fluid you need to know the pressure at a depth above the fluid. In an open container at sea level, what is the value of that pressure?
101.3kPa or 101,300Pa
100
If a liquid has a density of 1.4 g/ml, will it float or sink in water?
sink
100
If a 200ml volume of liquid come out of a pipe every second and has a density of 7.89g/ml, what is the mass flow rate of the liquid?
1.578kg/second
100
This vehicle gets Batman from A to B
The Batmobile
200
What is the metric unit for Pressure?
Pascal or kilopascal
Pa or kPa
200
In a closed, fluid filled container, how much force is applied to a piston with an area of 3cm^2 that counteracts a force of 200N on a separate piston with an area of 30cm^2?
20N
200
How much pressure is at the bottom of a 0.2m glass of Coke? Assume density to be the same as water.
103,260 Pa
200
If a 20kg floating raft has an upward buoyant force of 300N what is the opposing force of gravity?
300N
200
If a section of pipe has a diameter of 3cm and has a liquid flowing through it at a rate of 1m/s, what is the flow rate of the liquid?
7.065x10^-4m^3 per second
200
This talking 1982 Pontiac Trans. Am starred beside David Hasselhoff's character in the hit show "Nightrider"
Kitt
300
What is the difference between force and pressure?
300
How much force can a 0.5 m piston hold if the opposite piston holds 10N and has a radius of 0.1m?
pi*r^2=A
50N
300
What is the gauge pressure at the bottom of a 20m deep swimming pool?
196,000 pascals
300
If a toy boat displaces 0.02m^3 of water, what is the buoyant force on the boat?
196N
300
If a liquid flows through a pipe with a diameter of 1.5m at the rate of 120m^3/s, what is the velocity of the liquid?
68m/s
300
This backstreet racing machine starred alongside Vin Diesel in a number of films.
1970 Dodge Charger
400
Density = ?
400
How much force is applied to a piston with a diameter of 3cm to lift a 1000kg object sitting on a 0.5m piston?
35N
400
What is the gauge pressure 300m below the ocean in psi? (6895 Pa in 1psi)
426psi
400
Engineering clubs often compete in the "concrete canoe" competition. Each club creates a canoe out of concrete and then the clubs race those canoes to find out whose design is best.
If a concrete canoe weighs 1334N (300Lbs), how much water will it need to displace to float?
0.136 m^3
400
A grain elevator can fill a train car in 30s. If the train car measures 3m x 3m x 20m, what is the volume flow rate?
6m^3/s
400
This orange 1969 dodge charger with a confederate flag on top was a symbol of rebellious spirt and in high demand during it's time on TV. The show destroyed more than 170 of these cars during its run time.
The General
500
What is the weight, in Newtons, of an object with a volume of 2L and a density of 0.3kg/L?
V x P = m
m x g = weight
2L x 0.3kg/L = 0.6kg
0.6kg x 9.8m/s^2 = 5.88N
500
How many 80kg people need to stand on a 2m^2 piston to lift an 800 kg mass on a 5m^2 piston?
500
What is the pressure difference in an open pool of gasoline between the shallow end (1meter) and the deep end (4 meters). (gasoline density is 800kg/m^3)
23520Pa
500
If a helium balloon floats through the air with a mass of 12g and a volume of 0.3m^3 what is the net force on the balloon. Assume no wind, and air density to be 1.2kg/m^3
0.1176N down
3.5N up
3.38N up Net force
500
Water is flowing through a high pressure mining hose at 30m/s and a pressure of 300,000 Pa. If the water exits the hose at atmospheric pressure, what is the velocity of the water coming out of the hose? Assume the hose is flat, height doesn't count.
50.9m/s
500
This furry ford Econoline was the main mode of transportation for the Lloyd and Harry.
The shaggin' wagon
