Points, Lines, Planes
Segments
Angles & Angle Pairs
Constructions
Distance & Midpoint
100
Name the line shown.
bar (CD) or bar (DC)
100
Point C has coordinate 4. Point D has coordinate 9. Point E has coordinate -1. Are the segments below congruent?
bar (CD) and bar (CE)
Yes
100
What is the supplement of a 92 degree angle?
88
100
True or False.
A protractor is permitted to use when making a construction.
False.
100
Find the midpoint of
(6, 8) and (10, -4)
(8, 2)
200
True or False.
Opposite rays will always form a straight line.True
200
Points A, B, and C are collinear with B between A and C. If AB = 15 and AC = 28, find BC.
BC = 13
200
Name a pair of vertical angles in the figure below.
Angles 2 and 6
200
What are the two tools used when constructing?
Compass and Straightedge
200
Find the distance between
(-2, 0) and (4, 12)
Round to the tenth.
13.4
300
Name the plane shown below.
Answers will vary
300
B is the midpoint of segment AC. If AC = 9, then what is AB?
4.5
300
Finish the linear pair postulate: If two angles form a linear pair, then they are _____________________.
supplementary
300
Which construction is shown below?
angle bisector
300
Find the midpoint of the segment below.
(0, 1)
400
Name the intersection of planes ABC and CHD.
bar (BC)
400
Find the value of x.
x = 13
400
Find the value of x.
x = 6
400
Which construction allows you to locate the midpoint of a segment?
perpendicular bisector
400
Find the distance between the two points rounded to the nearest tenth.
9.2
500
Finish the postulate....through any three noncollinear points there is exactly _______________________.
one plane
500
B is the midpoint of segment AC. Find the value of x.
x = 2
500
GH bisects angle FGI. Find the measure of angle FGI.
60
500
What went wrong in this construction?
The compass was not open wide enough for the arcs to intersect each other
500
Point M is located at (1, 5) and is the midpoint of segment AB. If A is at (-3, 9), what are the coordinates of point B?
(5, 1)
