ROCKETS
AWSE
GP BOMBS
MISSILES/LAUNCHERS
GBUs
100
How many rockets does the LAU-61 and LAU-68 hold?
LAU-61: 19x 2.75 inch rockets.
LAU-68: 7x 2.75 inch rockets.
100
The ADU-488/E is used in conjunction with what skid that has a SWL of 1,250?
AERO-12C
100
What WAM manual provides detailed information on MK 80/BLU Series bomb assembly/disassembly, practice bomb assembly/disassembly, MK 77 Fire Bomb assembly/disassembly and Armament Weapons Support Equipment (AWSE) requirements.
NAVAIR 11-140-5
100
What are the publications for HERO?
NAVSEA OP 3565/NAVAIR 16-1-529.
100
If a FZU-48 is to be used, what has to be removed?
If FZU-48 is to be used, ensure M70 Series cable has been removed
200
What Rocket Launchers are used with the APKWS?
Only the LAU-68F/A and LAU-61G/A are authorized for APKWS II.
200
When storing AIM-120 fins inside an ADU-488/E, what other adapter must you use?
ADU-628/E
200
What are the first five sections of a WAM manual?
SECTION I – INTRODUCTION.
SECTION II – DESCRIPTION.
SECTION III – CONFIGURATION
SECTION IV – BIT/TEST AND REPROGRAMMING.
SECTION V – COMMON PROCEDURES.
200
What is cook off time for the JSOW ?
5 minutes
200
As part of the MXU-667, MXU-650 and MXU-651 airfoil group (AFG) preparation/inspection, what color must the humidity indicator be?
Blue
300
What is the nomenclature for the Advanced Precision Kill Weapon System II (APKWS II)?
WGU-59/B
300
How many ADU-729/E's may be stacked on the AERO 12C?
The ADU-729/E may be stacked two high on the AERO 12C.
300
What is a Warning?
An operating procedure or practice which, if not correctly followed, could result in personal injury or loss of life.
300
What two launchers are used to create the monster configuration ?
LAU-115 and LAU-127
300
How many setscrews come with a MXU-650 and 651?
Eight
400
What is the purpose of the Stabilizing Rod in a Rocket?
The salt-coated stabilizing rod in the perforation of the motor propellant grain prevents unstable burning of the propellant and reduces flash and after-burning that contribute to compressor stall and flameout of jet aircraft engines.
400
What is the configuration of a MHU-191 with ADU-514/Es for Laser Guided Training Rounds?
Rail Holes 6/36
400
What is a Caution?
An operating procedure or practice which, if not strictly observed, could result in damage to, or destruction of, equipment.
400
The LAU-116 launches what weapons?
The LAU-116 is an eject type guided missile launcher designed to provide a mechanical and electrical interface between the aircraft weapon system and the AIM-120 Series or AIM-7 Series missile. The LAU-116 is used on F/A-18E/F, F/A-18A-D, and EA-18G aircraft and is installed in the underside of the aircraft fuselage allowing, the missiles to be semi recessed for aerodynamic purposes.
400
How many set screws come with a MXU-667?
Twelve
500
What Test Set is a self-contained, multipurpose Test Set powered by a Nickel Metal Hydride or alkaline battery and is used at the O-level and I-level?
AN/USM-715
500
What is the configuration of a MHU-191 with ADU-514/Es for hellfire missiles?
Rail Holes 15/35
500
What is a Note?
An operating procedure or condition which it is essential to highlight.
500
The AGM-88E AARGM missile uses what wings?
The BSU-103/E wing which is a modified BSU-59/E HARM wing.
500
What must be used to lift the BLU-109 bomb from the pallet and free suspension lugs from pockets of the pallet?
MK 102 or MK 111 Torpedo Sling
600
What NALC for APKWS is only authorized for rotor wing aircraft and what NALC is only authorized for fixed wing aircraft?
HA79 is ONLY authorized for rotor wing aircraft.
HB24 is ONLY authorized for fixed wing aircraft.
600
What is the configuration of a MHU-191 with ADU-514/Es for Sparrow missiles?
Rail Holes 1/36
600
The battery paint band on the DSU-33B/B will appear what color if battery has not been activated?
White or Light Grey
600
What is the weight of the AIM-120C ?
356.0
600
What is the average cook off time for MK.82, 83, and 84 MODs Unprotected?
3 minutes and 30 seconds
700
What is the maximum number of inoperable tubes a LAU-61 and a LAU-68 can have?
The maximum number of inoperable tubes is: three for the LAU-61, and one for the LAU-68.
700
What is the configuration of a MHU-191 with ADU-514/Es for AIM-9X missiles?
Rail Holes 6/36
700
How much thermal coating can be missing from a General Purpose Bomb and if it is missing the amount of thermal coating it needs what C/C would it be given?
Less than 56 sq. ins. (cumulative).
Less than 15 sq. ins. in any one area.
C/C: F
700
What two launchers are used to fire the AGM-114 series missile?
M272/M299
700
What is the average cook off time for the MK 83 MODs/BLU-110A/B that is Thermally Protected?
10 minutes
800
What is the drop criteria for Rockets and Rocket Motors?
Do not use rockets or rocket motors if dropped any distance. This requirement takes precedence over the 2-foot drop requirement if cited on rocket motor stencil. The term DROP is defined as to suddenly descend from one level to another.
800
What is the configuration of a MHU-191 with ADU-514/Es for AIM-120 missiles?
Rail Holes 6/47
800
What are the only high drag arm/delays settings authorized on a FMU-139 with a MK122 safety switch?
2.6/INST, 2.6/10, 2.6/25 and 2.6/60 are the only high drag arm/delays authorized.
800
What is the downing criteria for the HAS (Hydraulic Actuation System) on the AGM-65 ?
Fill port missing or Fluid leaking
800
What is the drop criteria for bomb bodies in and out of the container?
6 Feet
900
What adapters are authorized for assembling the APKWS II?
There are two authorized adapters for assembling APKWS II. The Strap Wrench Adapter (SWA) or the improved Torque Ring Adapter (TRA).
900
What is the single lift capacity and the double lift capacity of HLU-288/E ?
SINGLE : 2,240 LBS
DOUBLE : 4,480 LBS
900
In the event of obvious defect or leakage of a CXU-3A/B and CXU-4/A/B signal cartridge, how do you neutralize the hydrochloric acid?
Immerse spotting charge in water. Neutralize the hydrochloric acid in the water by slowly adding 8 ounces (per cartridge) of bicarbonate of soda.
900
What is the diameter of the AGM-84H/K ?
13.5 inches
900
What is the difference between the DSU-38A/B and the DSU -38/B ?
DSU-38A/B incorporates a APS (Adjustable Proximity system)
1000
What are the only warheads approved for use with the WGU-59/B?
The only warheads approved for use with the WGU-59/B are the M151 HE equipped with the M423 fuze, the MK 152 HE warhead, and the WTU-1/B.
1000
What is the Nomenclature for the third tier of ADU-514s?
ADU-829/E
1000
When using MK 122 switch in conjunction with MK 84 bomb body, what mod of the Mk 84 must be used and why?
MK 84 MOD 6 or 7must be used.
The charging well on the MODs 6 and 7 has been moved approximately 3 inches aft so the bomb can be used with the BRU-32 bomb rack on the F/A-18.
1000
How much does a AGM-84D Harpoon weigh?
1,160 lbs.
1000
A pull force of how many pounds or greater will activate and render the FZU-48 unserviceable?
A pull force of 30 pounds or greater will activate and render the FZU unserviceable.
