Doppelmayr Line Maintenance
Grip Maintenance
Carrier Maintenance
Haulrope Maintenance
Brakes
Rails
Electrical
General
10
What should be read over before starting line work on any chair?
Line work Procedure
10
What do you do to the haul rope before relocating a YAN grip?
Paint and lube it
10
What is a non – conforming bail?
The front bar Is straight compared to a bent bar
10
What is a lay length?
One complete rotation of a strand
10
What primary oil do we use in most of our brake systems?
6522
10
What is the max depth of a single groove, triple groove PTO as well as a deflector?
12.5mm/6mm/14.5mm
10
Demonstrate the proper way to crimp a quick disconnect?
Show me.
10
Explain what is happening when you are completing your AC test in the morning?
You are either turning that switch on or off, simulating a grip being there or a broken switch
20
What are the three most common sheaves on a Doppelmayr lift?
401,403,501
20
Draw a D & T spring pack.
20
What is the proper torque value for an E-model taco bolt?
150ft lbs.
20
What is a strand?
A make up of a certain amount of wires twisted together
20
What is the proper clearance for a Doppelmayr e brake and roll back pad? Where do you measure it?
3/3 from the center
20
Newest member only: name the grip switches in order?
We know the answer.
20
Explain the colors of an RPD wire, order and description?
Brown/24v, Black/return, White/test, Blue/common
20
Explain the order of operation when parking and loading chairs 1 & 16?
Explain
30
What are the 8 most common items you need to change all the Doppelmayr sheaves?
10mm Allan, 30mm, 36mm, Bullet, Grease, Come a Long, Rope Jack, Sling, Rope, Haul Bag
30
What are the required measurements for Doppelmayr grip maintenance?
Running wheels, guide, actuating, distance A
30
How many areas need to be NDTed on a Yan triple carrier?
17
30
What is the minimum and maximum diameter of a haul rope?
6% min 8% max
30
When referencing stopping distances, where should you get the proper measurements from?
Original load test
30
What is the max degree the trumpet can be set to move?
5 degrees
30
Explain reference voltages and what faults they can cause?
8.5v at full speed motor and bull wheel tachos, actual actual or reference actual.
30
What are the two different types of spacing and give a brief explanation on how they work?
Explain
40
What should be done prior to servicing tower 1 on a Doppelmayr?
De tension and lock it out
40
What is distance A monitoring?
Grip jaw wear, Cable integrity
40
Demonstrate how to properly make and tie a seat string to completion.
Show Me
40
What is the minimum distance a fixed grip can be from a tuck or repair?
20 times the diameter of the haul rope.
40
Explain how the limit switch on a yan service break functions?
We know the answer
40
How do you align a PTO sheave and what tools do you need?
24” Crecent, 30mm wrench, 6’ straight edge/remove lock block with 30mm, turn axel with 24” Crecent in or out until aligned.
40
Draw a complete generic tower circuit, including boot?
Show me
40
Tie the following knots flawlessly: clove hitch, sheave knot, bowline, munter, figure 8
Demonstrate
50
Describe the process in order when building a 401 sheave (15 step)?
Press side plate, remove snap ring, flip, push off second side plate and liner, remove second snap ring, remove bearings, Gauge hub, clean, install bearings, install first snap ring, install first side plate, push on liner, install second side plate with snap ring, press and install final snap ring, inspect and write employee number on hub.
50
When a Yan 3 grip slips on pull test, how do you tension it and what tools do you need?
9/16 wrench, 9/16 socket, diagonal cutters, 2 3/16 socket with ratchet. Remove cotter pin, remove puzzle piece, turn bolt half a turn, pull test, turn one more half in necessary, reinstall cotter pin, re install puzzle piece.
50
Explain the two different sets of hardware that suspend the panorama and village gondolas, from the neck down?
PG 4 M16 and 4 pins/VG 2 axels and 4 pins
50
What is the minimum length of a splice on a 38mm haul rope?
45.6 meters
50
What are the 4 types of YAN e-brakes and what tonnage cylinder do they use?
940, 1100, 1500, 4000B/20ton, 30ton, 60ton, Air bladder
50
What is the proper degree set points for the haul rope from the coupling area down to the bull wheel?
3 sheave 1,3,5/ 4 sheave 1.25,2.5,3.75,5
50
When going to meg a motor explain the process and what you are looking for?
Electrician give me
50
Name all the state requirements we need to have done by the time the chair opens?
Line main, grip maint, grip ndt, carrier maint, carrier ndt, brakes, haul rope, rails, electrical PM, state inspection, grip force, tower foundations, tension system maintenance
